NURASPIKE

Anchor 1

The Nuraspike is a powder-coated galvanized steel footing that is 500mm long and is designed to be driven flush into the ground with a sledge hammer.  Placing an adjustable Nurajack (available in sizes from 28mm to 550mm) directly under joist or bearer on top of the Nuraspike to create a low-profile deck over grass or dirt.



The Nuraspike installation does not require any digging or concrete.

​The Nurajack can be placed anywhere on the top of the Nuraspike - and with the self-levelling head of the Nurajack, there is no need to line up the Nuraspike or ensure the Nuraspike is level when installing. Once the Nuraspikes and Nurajacks are installed, the deck structure can be built.

For tiled decks over the Nuraspike system, an aluminium frame must be installed. See www.outdure.com for more information.


FEATURES


SIMPLE

Install with an adjustable Nurajack directly under a joist or bearer to create a low-profile deck over grass or dirt


ELIMINATES EXTRA BACK BREAKING WORK

No boring or digging of large holes required, simply hammer into the ground


DURABLE

Made from powder-coated galvanized steel to stand the test of time


SAVE TIME & EFFORT

No concrete needed, instead the unique Nuraspike design supports a Nurajack firmly on the ground


HIGH QUALITY

New Zealand designed and manufactured to the highest standards


STRONG

Can withstand being installed with a sledge hammer – when used with a Nuraspike Hitting Plate (available separately)

noun-easy-2916907-6A93CC (1).png

DECKING MADE EASY

Use with any combination of Nurajacks

Nuraspike For Timber Decks

How to assemble a Nuraspike

PRECAUTIONS

  • Check for in-ground services where Nuraspike is being installed.


  • Nuraspikes must be installed flush in ground.

  • Not suitable for waterlogged, heavily compacted or rocky soil. If in doubt, test the area first or check with a qualified engineer.

  • Use Nuraspike Hitting Plate (available separately).

  • Ensure deck complies with any relevant local or governmental building requirements.

  • Assemble Nuraspike completely before installation.

  • Follow timber suppliers specifications for deck structure and placement of decking boards.

  • Nurajack Placement Graph can be found on Nurajack box.

Placement Graph.jpg
